PMP-600 Pump, G 1/4 BSP

Part No. PMP-600 In-Stock Icon In Stock Fedex orders placed now will ship on July 6th.
$94.99
Volume Pricing
Qty 1 : $94.99/ea
10 : $91.12
25 : $87.24
50 : $83.37
100 : $82.21
250 : $80.27
500+ : $79.11
RoHS CertifiedREACH Certified

PMP-600 provides the highest overall output among Koolance's 24V pumps. A mounting bracket is included.

  • Maximum Flow Rate: 20L/min (5.3 gal/min)
  • Maximum Head Pressure: 11m (36ft)
  • Motor: Brushless DC
  • Power Consumption (at max): 52W
  • Voltage Range: 8 to 24 VDC
  • Maximum Temperature: 75°C (167°F)
  • Electrical Connector: 4-pin Molex power supply connection + 3-pin (single lead) tach
  • Hose Connections: G 1/4 BSPP Threads
  • Noise: Less than 50dBA
  • Weight: 454g (1lbs)

General
Weight 1.20 lb (0.54 kg)
Fitting Thread G 1/4 BSPP
Max Pressure @ 25°C 1.5kgf/cm2 (21.3psi)
Max Temperature 75°C (167°F)
Pumps
Expected Lifetime 30,000 hrs. MTBF
Max Flow Rate 20L/min (5.3 gal/min)
Max Power 52W
Max Static Head 11m (36ft)
Native Hose Connection G 1/4 BSP Threads
Speed Knob no
Tachometer yes
Type Magnetic Centrifugal
Voltage 8-24 VDC
Dimensions
Diagrams / Models (See Files Tab for Diagrams and 3D Models)

Diagram - pmp-600_d1.pdf
3D Model - pmp-600.step.zip

Liquid Coolants

Koolance's product warranty does not cover the use of 3rd-party coolants, coolant additives, or corrosion. Koolance LIQ-702 or LIQ-705 coolants are strongly recommended to help avoid issues with mixed metals or biological growth. Additionally, do not use aluminum with bare (unplated) copper or bare (unplated) brass in the same system. Do not use silver with nickel in the same system.
